PM983
Features And Benefits ▼
This Samsung PM983 2.5" U.2 NVMe SSD adopts PCIe Gen3 x4 high bandwidth interface, breaking SATA performance bottleneck. Optimized NVMe protocol delivers ultra-low latency and excellent sequential & random I/O performance. It greatly improves response speed for cloud servers, database and cache workloads compared with traditional SATA enterprise SSDs.
Equipped with hardware Power Loss Protection circuit. When unexpected power failure occurs, built-in capacitors supply temporary power to flush cache data into flash. Combined with end-to-end ECC error correction and AES-256 encryption, this server solid state drive effectively avoids data corruption and guarantees enterprise data security.
Based on mature Samsung 3D V-NAND and enterprise firmware, PM983 supports non-stop long-time server operation. Rated MTBF reaches 2 million hours with strict JEDEC enterprise reliability standard. Dynamic & static wear leveling algorithm extends service life under mixed read-write data center scenarios.
Universal 7mm 2.5-inch U.2 form factor fits most mainstream rack server drive bays. Direct hot-swap support without hardware modification. System integrators can easily upgrade existing server storage architecture, reducing deployment time and reconstruction cost for data center renovation projects.
As balanced entry-to-mid enterprise NVMe SSD, PM983 provides far higher IOPS performance than SAS/SATA HDDs with competitive per-TB cost. Perfect for read-heavy and mixed workloads, helping enterprises balance storage performance and capital expenditure for cloud hosting and medium-scale data services.
Parameter Item Specification ▼
Parameter Item | Specification Value |
|---|---|
Model | Samsung PM983 (2.5" U.2) |
Form Factor | 2.5-inch U.2 SFF (7mm) |
Interface | PCIe Gen 3.0 x4, NVMe 1.3 |
Flash Type | Samsung 3D V-NAND TLC |
Available Capacity | 960GB / 1.92TB / 3.84TB /7.68TB |
Sequential Read | Up to 3,500 MB/s |
Sequential Write | Up to 2,400 MB/s |
Random 4KB Read | Up to 520,000 IOPS |
Random 4KB Write | Up to 45,000 IOPS |
Endurance Rating | 1.3 DWPD (3 Years) |
MTBF | 2,000,000 Hours |
UBER | 1 sector per 10¹⁷ bits read |
Core Protection | PLP Power Loss Protection, End-to-End Data Protection, AES 256 Encryption |
Operating Temperature | 0 ℃ ~ +70 ℃ |
Typical Active Power | 8.7W ~10.6W; Idle: 4.0W |
Work Mode | 7×24 Hours Enterprise Continuous Operation |
Application | Server, Data Center, Cloud, Database Cache |
Typical Application Scenarios ▼
This Samsung PM983 2.5" U.2 NVMe SSD adopts PCIe Gen3 x4 high bandwidth interface, breaking SATA performance bottleneck. Optimized NVMe protocol delivers ultra-low latency and excellent sequential & random I/O performance. It greatly improves response speed for cloud servers, database and cache workloads compared with traditional SATA enterprise SSDs.
Equipped with hardware Power Loss Protection circuit. When unexpected power failure occurs, built-in capacitors supply temporary power to flush cache data into flash. Combined with end-to-end ECC error correction and AES-256 encryption, this server solid state drive effectively avoids data corruption and guarantees enterprise data security.
Based on mature Samsung 3D V-NAND and enterprise firmware, PM983 supports non-stop long-time server operation. Rated MTBF reaches 2 million hours with strict JEDEC enterprise reliability standard. Dynamic & static wear leveling algorithm extends service life under mixed read-write data center scenarios.
Universal 7mm 2.5-inch U.2 form factor fits most mainstream rack server drive bays. Direct hot-swap support without hardware modification. System integrators can easily upgrade existing server storage architecture, reducing deployment time and reconstruction cost for data center renovation projects.
As balanced entry-to-mid enterprise NVMe SSD, PM983 provides far higher IOPS performance than SAS/SATA HDDs with competitive per-TB cost. Perfect for read-heavy and mixed workloads, helping enterprises balance storage performance and capital expenditure for cloud hosting and medium-scale data services.
FAQ ▼
Q1: What interface and form factor is PM983?
A: 2.5-inch U.2 SFF, PCIe Gen3 x4 NVMe protocol.
Q2: Does PM983 support power loss protection?
A: Yes, built-in hardware PLP capacitor circuit to protect cached data during sudden power outage.
Q3: What workload fits PM983 best?
A: Read-intensive and mixed read/write scenarios; not designed for continuous heavy write workloads exceeding 1.3 DWPD.
