The AMD EPYC 7K62 is a 2nd Generation EPYC 7002 Series processor built on the Zen 2 microarchitecture, codename Rome. It is designed for data center and enterprise server deployments that require high core density, memory bandwidth, and I/O expandability within a single-socket or dual-socket SP3 platform. The processor is supplied as an OEM tray unit and targets system integrators, data center operators, and commercial procurement teams building rack-scale infrastructure.
Model | AMD EPYC 7K62 |
|---|---|
Official Tray PN | 100-000000109 |
Architecture | Zen2 (7002 Series Rome) |
Core / Thread | 48 Core / 96 Thread |
Base Frequency | 2.6 GHz |
Max Boost Frequency | Up to 3.3 GHz |
L3 Cache | 240 MB |
Socket | SP3 |
Supported Configuration | 1-Socket / 2-Socket |
Memory Support | 8 Channel DDR4 ECC, up to 3200 MT/s |
PCIe Interface | PCIe 4.0, total 128 Lanes |
Process Technology | TSMC 7nm |
Default TDP | 240 W |
Security Tech | AMD Infinity Guard Secure Encryption |
The EPYC 7K62 provides 48 physical cores and 96 threads via Simultaneous Multithreading. It operates at a 2.6 GHz base frequency with a maximum boost frequency of 3.3 GHz. The 240MB shared L3 cache reduces memory access latency for cache-resident datasets, supporting workloads such as virtual machine consolidation and container orchestration. Manufactured on TSMC 7nm process technology, the processor maintains a 240W default TDP.
This processor integrates 128 PCIe 4.0 lanes, enabling direct attachment of NVMe SSDs, 100GbE network adapters, and compute accelerators without an additional PCIe switch. The integrated memory controller supports eight channels of DDR4 ECC memory at speeds up to 3200 MT/s, providing error-correcting memory capability required for enterprise and mission-critical deployments.
The EPYC 7K62 supports both 1-socket and 2-socket configurations using AMD Infinity Fabric interconnect. A dual-socket node scales to 96 cores and 192 threads, allowing enterprise buyers to match compute density to workload requirements without migrating to a new platform architecture.
The processor includes AMD Infinity Guard, a set of hardware-level security features covering Secure Memory Encryption (SME) and Secure Encrypted Virtualization (SEV). These functions help industrial clients meet data protection compliance requirements in financial, healthcare, and private cloud environments.
With 96 threads per socket, the EPYC 7K62 supports high VM and container density per physical server, reducing the number of physical nodes required for public cloud, private cloud, and VDI deployments.
The combination of 128 PCIe 4.0 lanes and 8-channel memory supports HCI nodes that converge compute, storage, and networking. The PCIe 4.0 bandwidth accommodates multiple NVMe drives for software-defined storage tiers.
The 240MB L3 cache and memory bandwidth benefit in-memory databases, distributed cache services such as Redis, and relational database workloads such as PostgreSQL and MySQL by reducing disk I/O frequency.
The EPYC 7K62 is supplied as an OEM tray processor with Tray PN 100-000000109. Tray packaging is standard for volume procurement by system integrators and data center operators. Bulk pricing, lead time, and warranty terms are available upon request. All units undergo functional testing before shipment.
Both are 48-core Zen 2 SP3 processors. The EPYC 7K62 has a 2.6 GHz base frequency and 240W TDP, while the EPYC 7642 has a 2.4 GHz base frequency and 225W TDP. The 7K62 is an OEM-specific SKU.
The processor supports DDR4 ECC memory at up to 3200 MT/s across eight channels. ECC memory is recommended for enterprise server deployments to detect and correct single-bit memory errors.
The EPYC 7K62 uses the SP3 socket and is compatible with motherboards designed for AMD EPYC 7002 Series processors, including dual-socket server motherboards from major OEM and ODM vendors.
The processor has a 240W default TDP and requires a server-grade SP3-compatible air or liquid cooling solution rated for at least 240W. Specific cooler compatibility depends on the server chassis and motherboard design.
The EPYC 7K62 is an OEM tray processor and is not sold in standard retail packaging. It is supplied in tray format for volume integration by system builders and data center procurement teams.
