Intel Xeon Gold 6312U
Xeon Gold 6312U belongs to Intel 3rd‑Generation Xeon Scalable Ice Lake series, built on 10nm manufacturing process, single‑socket only processor with 24 cores and 48 threads via Intel Hyper‑Threading technologyIntel. Base frequency 2.4GHz, maximum turbo frequency up to 3.6GHz, equipped with 36MB shared cache, TDP 185WIntel®.
It supports 8‑channel DDR4‑3200 ECC registered memory, maximum capacity up to 6TB, compatible with Intel Optane DC persistent memory, delivers high‑reliability for large‑memory workloadsIntel. Provides 64 PCIe 4.0 lanes for high‑speed SSD, network card and accelerator expansion. Integrated AVX‑512 instruction set and Intel DL Boost, accelerates AI inference, computing and data processing tasksIntel.
This CPU is for FCLGA4189 socket single‑socket server platforms. Widely applied in enterprise server, virtualization host, cloud node, database, storage server and data center computing tasks. High‑performance server cooling solution is required for stable full‑load operationIntel®
The Intel Xeon Gold 6312U belongs to 3rd‑generation Intel Xeon Scalable Ice Lake‑SP family, designed exclusively for single‑socket enterprise server platformsIntel®. Equipped with 24 physical cores and 48 SMT multi‑threads, this CPU delivers massive multi‑thread throughput for data‑intensive workloads. Optimized for single‑socket rack server deployment, it meets rigorous computing demands of data center virtualization, cloud host, database service and batch parallel computing scenarios.
2. 2.4GHz Base / Up to 3.6GHz Max Turbo Frequency & Large‑Capacity Cache
Running at 2.4GHz base frequency and up to 3.6GHz maximum turbo frequency, it balances sustained multi‑core load performance and burst single‑task response. Built‑in 36MB shared L3 smart cache effectively reduces memory access latency, accelerates database query, virtual machine scheduling and large‑scale data processing, improving overall server throughput under heavy continuous workloads.
3. High‑Speed Memory & Rich Expansion Capability
Support 8‑channel DDR4‑3200 ECC memory, maximum memory capacity up to 6TB, compatible with Intel Optane persistent memory, offering reliable large‑capacity memory solution for memory‑intensive services. It provides 64 PCIe 4.0 lanes, supports high‑speed SSD, network card and accelerator card expansion. Adopt FCLGA4189 socket, match C620 series chipset motherboards, stable for long‑term 24/7 enterprise operationIntel.
4. 185W TDP, Complete Server‑Grade Security & Virtualization Technologies
With 185W nominal TDP, it requires qualified server cooling solution for full‑load stable operation. Integrated comprehensive enterprise‑level technologies: Intel VT‑x / VT‑d hardware virtualization, AVX‑512 advanced instruction set, ECC error correction, platform security enhancement. It supports large‑scale virtual machine deployment, container operation and encryption computing, satisfying enterprise data security requirements. Note: This processor has no integrated graphics output.
5. Reliable Data‑Center‑Grade IC Quality & Wide Enterprise Compatibility
Manufactured according to strict Intel server processor standards, Tcase maximum operating temperature 80°C, supporting non‑stop day‑and‑night runningIntel. Widely used for new server assembly, data‑center hardware refresh, second‑hand server reconstruction and enterprise equipment replacement. It is a cost‑effective single‑socket high‑core‑count compute component.
Item | Specifications |
|---|---|
Part Number | Intel Xeon Gold 6312U |
Product Series | 3rd Gen Intel Xeon Scalable (Ice Lake‑SP) Server Microprocessor IC |
Architecture | Ice Lake‑SP |
Process | Intel 10nm |
Core / Thread | 24 Cores / 48 Threads (SMT Enabled) |
Base Frequency | 2.4 GHz |
Max Turbo Frequency | Up to 3.6 GHz |
L3 Cache | 36 MB Smart Cache |
Default TDP | 185 W |
Socket | FCLGA4189 (Single‑socket only) |
Memory Support | 8‑Channel DDR4‑3200 ECC, Max 6TB, Intel Optane Persistent Memory supported |
PCIe Version | PCIe 4.0, 64 Lanes |
Integrated Graphics | None |
Key Instruction | AVX‑512, SSE4.2, TSX‑NI |
Virtualization | Intel VT‑x, VT‑d |
Max Case Temperature | 80°C |
Core Advantages | 24C48T high multi‑thread performance, 8‑channel large memory support, PCIe4.0, rich enterprise feature set, cost‑effective single‑socket data‑center solution |
Application Grade | Data Center Servers, Virtualization Hosts, Cloud Computing Nodes, Database & Storage Servers, Parallel Computing, Enterprise Hardware Refresh & Refurbishment |
1. Enterprise Virtualization & Cloud Computing Server Nodes
The Xeon Gold 6312U serves as the core computing unit for single‑socket virtualization servers. Massive 24‑core 48‑thread resources support large quantities of concurrent virtual machines and container instances, improving hardware resource utilization for private cloud and enterprise IT infrastructure.
2. Database, Storage & Big‑Data Processing Servers
8‑channel high‑speed ECC memory and large cache deliver stable performance for relational database, distributed storage and big‑data analysis workloads. Reduce data read‑write latency, suitable for enterprise business data service deployment.
3. Parallel Computing & Batch Processing Workloads
Powerful multi‑thread capability handles offline data calculation, simulation analysis, media transcoding and batch task scheduling, ideal for medium‑size compute nodes in industrial and research scenarios.
4. High‑Density Rack‑mount Server Assembly & Deployment
Optimized for single‑socket rack‑mount server hardware. It is widely adopted for new‑machine building, data‑center capacity expansion and legacy server performance upgrade, balancing computing power and procurement cost.
5. Server Hardware Refurbishment & Secondary Market Replacement
As mature 3rd‑gen Xeon scalable processor IC, it features good compatibility with FCLGA4189 mainboards. Frequently used for refurbished server reconstruction and bulk enterprise hardware replacement projects.
