Xeon Gold 6314U belongs to Intel 3rd‑Generation Xeon Scalable Ice Lake series, manufactured on 10nm process, single‑socket only processor with 32 cores and 64 threads via Intel Hyper‑Threading technology. Base frequency 2.3GHz, maximum turbo frequency up to 3.4GHz, equipped with 48MB shared cache, TDP 205WIntel.

It supports 8‑channel DDR4‑3200 ECC registered memory, maximum capacity up to 6TB, compatible with Intel Optane DC persistent memory for large‑capacity reliable memory workloadsIntel®. Offers 64 PCIe 4.0 lanes for high‑speed NVMe SSD, network card and accelerator expansion. Built‑in AVX‑512 instruction set and Intel DL Boost, accelerates AI inference, numerical computing and big‑data processing tasksintel.eu.

This CPU is designed for FCLGA4189 single‑socket server platforms. Widely deployed in enterprise server, virtualization host, cloud node, relational database, storage server and data center computing scenarios. High‑end server cooling solution is required to guarantee stable full‑load operation.

Intel Xeon Gold 6314U Server Processor Features

1. 32‑Core 64‑Thread Single‑Socket Enterprise Server Processor

The Intel Xeon Gold 6314U belongs to 3rd‑generation Intel Xeon Scalable Ice Lake‑SP family, designed exclusively for single‑socket enterprise server platformsIntel. Equipped with 32 physical cores and 64 SMT multi‑threads, this CPU delivers massive multi‑thread throughput for data‑intensive workloads. Optimized for single‑socket rack server deployment, it meets rigorous computing demands of data center virtualization, cloud host, database service and batch parallel computing scenarios.

2. 2.3GHz Base / Up to 3.4GHz Max Turbo Frequency & Large‑Capacity Cache

Running at 2.3GHz base frequency and up to 3.4GHz maximum turbo frequency, it balances sustained multi‑core load performance and burst single‑task responseIntel. Built‑in 48MB shared L3 smart cache effectively reduces memory access latency, accelerates database query, virtual machine scheduling and large‑scale data processing, improving overall server throughput under heavy continuous workloads.

3. High‑Speed Memory & Rich Expansion Capability

Support 8‑channel DDR4‑3200 ECC memory, maximum memory capacity up to 6TB, compatible with Intel Optane persistent memory, offering reliable large‑capacity memory solution for memory‑intensive servicesIntel. It provides 64 PCIe 4.0 lanes, supports high‑speed SSD, network card and accelerator card expansion. Adopt FCLGA4189 socket, match C620 series chipset motherboards, stable for long‑term 24/7 enterprise operationIntel.

4. 205W TDP, Complete Server‑Grade Security & Virtualization Technologies

With 205W nominal TDP, it requires qualified server cooling solution for full‑load stable operationIntel. Integrated comprehensive enterprise‑level technologies: Intel VT‑x / VT‑d hardware virtualization, AVX‑512 advanced instruction set, ECC error correction, platform security enhancement, Intel DL Boost for AI inference workloads. It supports large‑scale virtual machine deployment, container operation and encryption computing, satisfying enterprise data security requirements. Note: This processor has no integrated graphics output.

5. Reliable Data‑Center‑Grade IC Quality & Wide Enterprise Compatibility

Manufactured according to strict Intel server processor standards, Tcase maximum operating temperature 81°C, supporting non‑stop day‑and‑night runningIntel. Widely used for new server assembly, data‑center hardware refresh, second‑hand server reconstruction and enterprise equipment replacement. It is a high‑core‑count cost‑effective single‑socket compute component.

Technical Specifications of Intel Xeon Gold 6314U

Industrial & Enterprise Applications of Intel Xeon Gold 6314U Processor IC

1. Enterprise Virtualization & Cloud Computing Server Nodes

The Xeon Gold 6314U serves as the core computing unit for single‑socket virtualization servers. Massive 32‑core 64‑thread resources support large quantities of concurrent virtual machines and container instances, improving hardware resource utilization for private cloud and enterprise IT infrastructure.

2. Database, Storage & Big‑Data Processing Servers

8‑channel high‑speed ECC memory and large cache deliver stable performance for relational database, distributed storage and big‑data analysis workloads. Reduce data read‑write latency, suitable for enterprise business data service deployment.

3. Parallel Computing & AI Inference Batch Processing Workloads

Powerful multi‑thread capability plus Intel DL Boost handles offline data calculation, simulation analysis, media transcoding and AI inference batch task scheduling, ideal for medium‑size compute nodes in industrial and research scenarios.

4. High‑Density Rack‑mount Server Assembly & Deployment

Optimized for single‑socket rack‑mount server hardware. It is widely adopted for new‑machine building, data‑center capacity expansion and legacy server performance upgrade, balancing high core count and procurement cost.

5. Server Hardware Refurbishment & Secondary Market Replacement

As mature 3rd‑gen Xeon scalable processor IC, it features good compatibility with FCLGA4189 mainboards. Frequently used for refurbished server reconstruction and bulk enterprise hardware replacement projects.
