DN6838 is a bipolar Hall‑effect switch sensor manufactured by Panasonic, packaged in 3‑pin SIP through‑hole form factor. The chip integrates Hall element, amplifier and comparator circuit inside, responds to alternating magnetic field from small permanent magnet and outputs digital switching signal.

Operating supply voltage ranges from 4.5V to 12V. Operating magnetic flux density is 300Gauss. Wide temperature range from ‑40℃ up to +100℃ fits harsh working environment. Output stage can directly interface with DTL, TTL and MOS‑level ICs, no extra driving circuit required. Contact‑less magnetic detecting brings nearly unlimited service life compared with mechanical switches.

Pin definition: Pin1 Vcc, Pin2 GND, Pin3 Output. Widely used for motor rotation detection, rotary encoder, position detection, proximity trigger switch for home appliances and industrial equipment. Correct mounting and matched magnet are required for stable performance.

DN6838 Hall‑Effect Switch Sensor IC Features

1. Bipolar Hall‑Effect Magnetic Switch Sensor DN6838 is a bipolar hall‑effect switch sensor IC manufactured by Panasonic. It responds to alternating magnetic field changes, adopts passive pull‑up output structure, supports direct driving for DTL, TTL and MOS level circuits, features semi‑permanent contact‑less service life, stable and reliable magnetic trigger detection performance for industrial control equipment。

2. Wide Operating Temperature & Stable Electrical Performance Operating supply voltage up to 12V, wide working temperature from ‑40℃ to +100℃, adapts to harsh industrial ambient conditions. Small‑size 3‑pin through‑hole SIL plastic package, easy for PCB through‑hole mounting, compact footprint for space‑constrained equipment design。

3. Passive Pull‑up Output Interface Passive pull‑up output design simplifies peripheral circuit design. Compatible with common logic control chips, no complex peripheral auxiliary components required, ideal for magnetic trigger, rotation speed detection and position feedback signal acquisition scenarios。

4. Contact‑less Detection & High Reliability Non‑contact magnetic sensing principle eliminates mechanical wear, realizes long‑term stable operation. Suited for continuous repetitive trigger tasks, greatly reduces equipment failure rate caused by mechanical switch aging。

5. Industrial‑Grade Component Compatibility Original Panasonic industrial hall sensor, widely used for aftermarket replacement and new‑build equipment. Mature device for automation equipment, household appliances, motor rotational monitoring and position switch modules。

Technical Specifications of DN6838

Industrial & Enterprise Applications of DN6838

1. Rotational Speed & Rotation Monitoring Detect rotating magnet signal for motor rotation monitoring, tachometer signal acquisition, rotary encoder auxiliary sensing for automation equipment.

2. Position & Limit Sensing Switch Magnetic‑trigger position feedback, limit switch replacement for mechanical equipment, non‑contact position detection module.

3. Household Appliance & Motor Control System Applied in home appliance control unit, small motor state detection, magnetic trigger signal output for consumer electronic devices.

4. Industrial Automation Trigger Module Non‑contact magnetic trigger for automation machinery, signal input for PLC and logic control circuit.

5. Equipment Maintenance & Refurbishment Replacement Original replacement component for legacy equipment repair, widely stocked for electronic component BOM maintenance and aftermarket repair projects。
