AMD EPYC 7002
EPYC 7002 series, codenamed Rome, is AMD second‑generation EPYC data center processor, adopting advanced TSMC 7nm Zen2 chiplet designAMD. The product portfolio covers 8‑64 physical cores, 16‑128 threads via SMT simultaneous multi‑thread technology, L3 cache from 64MB‑256MB, configurable TDP ranges from 120W‑280W. Models with suffix‑P are single‑socket only, standard models support both 1‑socket and 2‑socket dual‑socket configuration.
It features 8‑channel DDR4‑3200 ECC registered memory, maximum memory capacity up to 4TB per socket. Provides full 128 PCIe 4.0 lanes for high‑speed NVMe SSD, network adapters and accelerator expansion. Integrated AMD Infinity Guard hardware security suite delivers hardware‑level data protection for data center environmentAMD.
This processor uses SP3 socket server motherboard. Main application scenarios include enterprise virtualization host, relational database, hyper‑converged server, high‑performance computing HPC and cloud infrastructure. Dedicated server cooling solution is required for stable full‑load running.
1. 8‑64 Core Zen2 Rome Enterprise Server Processor Family The AMD EPYC 7002 series (codename Rome) is the 2nd‑generation EPYC server processor built on TSMC 7nm Zen2 chiplet architectureAMD. Covering core configurations from 8 cores up to 64 cores with SMT multi‑threading, this family delivers balanced compute density, excellent energy efficiency and flexible core‑count selection. It supports single‑socket and dual‑socket SP3 platforms via Infinity Fabric xGMI interconnect, widely deployed for enterprise virtualization, relational database, HPC simulation and hyper‑converged infrastructure workloads。
2. Flexible Frequency Range & Large Shared L3 Cache Base frequency ranges from 2.0GHz to 3.35GHz, max boost frequency up to 3.4GHz depending on specific SKU. The series provides up to 256MB large shared L3 cache, effectively reducing memory access latency, accelerating database query, virtual machine scheduling and parallel computing tasks, maintaining stable throughput under long‑term enterprise‑grade loads戴尔。
3. 8‑Channel DDR4 & Full‑Featured PCIe 4.0 Expansion Support 8‑channel DDR4‑3200 ECC registered memory, maximum memory capacity up to 4TB per socket, delivering high memory bandwidth for memory‑intensive workloadsAMD. Offering 128 PCIe 4.0 lanes, compatible with high‑speed NVMe SSD, 100G network adapters and GPU accelerators. Adopt SP3 socket, supporting 24‑7 non‑stop data‑center‑grade continuous operationAMD。
4. 120‑280W TDP Range, Complete Enterprise‑Grade Security & Function Set TDP ranges from 120W to 280W across different SKUs, requires matched server cooling solution for full‑load stable operation. Integrated AMD Infinity Guard security suite, including Secure Memory Encryption (SME), Secure Encrypted Virtualization (SEV), independent on‑board security processor, AMD‑V hardware virtualization, NUMA optimization, AVX2 instruction setAMD. Optimized for virtual machine deployment, container and database workloads. Note: This processor family does not integrate on‑board graphics output。
5. Datacenter‑Grade IC Reliability & Broad Enterprise Compatibility Manufactured under strict AMD data‑center processor specifications, designed for long‑term round‑the‑clock operation. Widely used for second‑hand server assembly, enterprise hardware refresh, refurbished server reconstruction and cost‑sensitive data‑center projects. It is a mature high‑value 2nd‑gen EPYC solution for general‑purpose enterprise scenariosAMD。
Item | Specifications |
|---|---|
Part Number | AMD EPYC 7002 Series (Rome‑Zen2) |
Product Series | 2nd Gen AMD EPYC 7002 (Rome‑Zen2) Server Microprocessor IC |
Architecture | Zen2 (Rome) |
Process | TSMC 7nm Chiplet |
Core / Thread | 8‑64 Cores / 16‑128 Threads (SMT Enabled) |
Base Frequency | 2.0‑3.35 GHz (SKU dependent) |
Max Boost Frequency | Up to 3.4 GHz (SKU dependent) |
L3 Cache | Up to 256 MB Shared Cache |
Default TDP | 120‑280 W (SKU dependent) |
Socket | SP3 (Support 1P / 2P via xGMI Infinity Fabric) |
Memory Support | 8‑Channel DDR4‑3200 ECC, Max 4TB per socket |
PCIe Version | PCIe 4.0, 128 Lanes |
Integrated Graphics | None |
Key Instruction | AVX2, AES‑NI |
Virtualization | AMD‑V hardware virtualization, SEV‑SME security encryption |
Core Advantages | Wide SKU selection from 8‑64 cores, mature 7nm Zen2 architecture, large L3 cache, 8‑channel DDR4‑3200, PCIe4.0 128 lanes, built‑in hardware security features, excellent cost‑performance for refurbished and cost‑sensitive data‑center deployment |
Application Grade | Enterprise Virtualization Hosts, Relational Database Servers, HPC Compute Nodes, Hyper‑Converged Infrastructure, Cloud Platforms, Enterprise Hardware Refresh & Refurbishment |
1. Enterprise Virtualization & Hyper‑Converged Servers EPYC 7002 series delivers flexible core‑count options for virtualization deployment, supporting large quantities of concurrent virtual machines, improving hardware utilization for private cloud and hyper‑converged infrastructure。
2. Relational Database & Business Application Servers Large L3 cache and 8‑channel high‑speed DDR4 memory reduce access latency, stable performance for OLTP database, middleware and enterprise business application workloads。
3. Cost‑Effective HPC & Batch‑Processing Nodes Wide‑range SKU portfolio adapts to different‑scale parallel computing, numerical simulation and offline batch‑processing tasks, ideal for cost‑sensitive compute cluster construction。
4. Storage‑Accelerated & High‑Throughput Data‑Center Servers Massive PCIe4.0 lanes support multiple NVMe SSD and high‑speed network adapters, suitable for software‑defined storage and high‑throughput data service deployment。
5. Refurbished Server & Enterprise Hardware Replacement Mature stable SP3 platform, abundant ecosystem motherboard support, widely applied for refurbished server assembly, enterprise hardware upgrade and budget‑friendly data‑center renovation projects。
