Xeon Bronze 3206r
Xeon Bronze 3206R belongs to Intel 2nd‑Generation Xeon Scalable Cascade Lake series, built on 14nm manufacturing process, without Hyper‑Threading, running 8 cores and 8 threads中关村在线. Base and maximum turbo frequency are both 1.9GHz, equipped with 11MB shared L3 cache, TDP 85W for low‑power stable operationIntel®.
It supports 6‑channel DDR4‑2133 ECC registered memory, maximum memory capacity up to 1TB, does not support Intel Optane DC persistent memory. Provides 48 PCIe 3.0 lanes for SSD, network card and peripheral expansion. Two UPI links enable dual‑socket 2‑processor configuration for multi‑CPU server platformsIntel. Integrated AVX‑512 instruction set and Intel DL Boost for light computing acceleration.
This CPU uses FCLGA3647 socket. Mainly deployed for entry‑level enterprise server, small business database, file storage server, basic virtualization host and office backend services. Dedicated server cooling solution is required for stable operation.
The Intel Xeon Bronze 3206R belongs to the 2nd‑generation Intel Xeon Scalable Cascade Lake family, supporting single‑socket and dual‑socket FCLGA3647 platformsIntel. Equipped with 8 physical cores and 8 threads without SMT hyper‑threading, this CPU delivers stable baseline computing performance. It is oriented for entry‑level rack server deployment, satisfying lightweight virtualization, file storage, small business application and basic data processing workloads with favorable cost‑performance ratio中关村在线。
2. 1.9GHz Fixed Frequency & Practical L3 Cache
Operating at fixed 1.9GHz base and max turbo frequency, it provides steady continuous computing capability for non‑burst enterprise services. Built‑in 11MB shared L3 cache reduces memory access latency, improves response efficiency for file access, small virtual machine instances and routine business tasks, suitable for long‑time stable running of entry‑level server systemsIntel。
3. Memory & Expansion Capability for Entry‑Level Enterprise Scenarios
Support 6‑channel DDR4‑2133 ECC memory, maximum memory capacity up to 1TB, ECC error correction ensures data reliability, Intel Optane persistent memory is not supportedIntel. Provide 48 PCIe 3.0 lanes, compatible with NVMe SSD, Gigabit / 10G network cards and expansion adapters. Adopt FCLGA3647 socket, match C620 series chipset motherboards, support 2‑socket UPI interconnection, adapt to mainstream 2nd‑gen Xeon server hardware environmentIntel®。
4. 85W Low TDP, Complete Basic Server‑Grade Technologies
With 85W nominal TDP, the processor has low heat generation, reduces cooling requirements for entry‑level servers, Tcase maximum operating temperature 78°CIntel. Integrate Intel VT‑x / VT‑d hardware virtualization, AVX‑512 instruction set, ECC memory error correction, platform security related functions. It supports small‑scale virtual machine deployment and enterprise security computing requirements. Note: This processor has no integrated graphics output。
5. Reliable Data‑Center‑Grade IC & Wide Refurbishment Compatibility
Manufactured in accordance with Intel server‑grade standards, supporting 24‑7 non‑stop operation. Widely used for new entry‑level server assembly, small enterprise IT construction, second‑hand server reconstruction and hardware replacement projects. It is a classic low‑power, cost‑effective entry‑level Xeon Scalable processor for aftermarket refurbishment marketHPE Tech L...。
Item | Specifications |
|---|---|
Part Number | Intel Xeon Bronze 3206R |
Product Series | 2nd Gen Intel Xeon Scalable (Cascade Lake) Server Microprocessor IC |
Architecture | Cascade Lake |
Process | Intel 14nm |
Core / Thread | 8 Cores / 8 Threads (No Hyper‑Threading) |
Base Frequency | 1.9 GHz |
Max Turbo Frequency | 1.9 GHz |
L3 Cache | 11 MB Smart Cache |
Default TDP | 85 W |
Socket | FCLGA3647 (Support 1P / 2P) |
Memory Support | 6‑Channel DDR4‑2133 ECC, Max 1TB, Intel Optane PMem not supported |
PCIe Version | PCIe 3.0, 48 Lanes |
UPI Links | 2 |
Integrated Graphics | None |
Key Instruction | AVX‑512, SSE4.2, AES‑NI |
Virtualization | Intel VT‑x, VT‑d |
Max Case Temperature | 78°C |
Core Advantages | Low 85W power consumption, stable 8‑core performance, dual‑socket support, low cooling requirement, excellent cost‑efficiency for entry‑level server and refurbishment projects |
Application Grade | Entry‑Level Rack Servers, Light‑weight Virtualization Hosts, File & Storage Servers, Small Business Application Servers, Server Refurbishment & Hardware Replacement |
1. Entry‑Level Enterprise Servers & Small Business IT Infrastructure
Xeon Bronze 3206R serves as cost‑effective compute core for small‑and‑medium enterprise servers. It handles office service, domain control, file sharing and business application workloads, lowering overall hardware procurement cost for corporate IT construction.
2. Light‑Weight Virtualization & Small‑Scale Host Nodes
8‑core stable performance supports a small quantity of virtual machines and container instances, applicable for private lab, branch office virtualization deployment scenarios.
3. File Storage & Backup Servers
6‑channel ECC memory and PCIe3.0 expansion deliver stable performance for NAS, backup storage and monitoring server, guaranteeing data integrity with ECC error correction function.
4. Dual‑Socket Entry‑Level Server Assembly Deployment
Support two‑socket configuration via UPI links, adopted for low‑cost dual‑socket rack‑mount server building for scenarios requiring moderate multi‑thread scalability.
5. Second‑hand Server Refurbishment & Bulk Hardware Replacement
Classic Cascade Lake generation FCLGA3647 CPU with abundant market stock and good motherboard compatibility. Frequently used for refurbished server reconstruction and enterprise old‑equipment replacement projects.
