Intel Xeon Gold 6442Y
Xeon Gold 6442Y belongs to Intel 4th‑Generation Xeon Scalable Sapphire Rapids series, manufactured on Intel7 process. Equipped with 24 cores and 48 threads via Intel Hyper‑Threading technologyDell. Base frequency 2.6GHz, maximum turbo frequency up to 4.0GHz, 60MB shared L3 cache, default TDP 225W, supports Intel SST‑PP for flexible core‑frequency and power‑performance tuningIntel.
It supports 8‑channel DDR5‑4800 ECC registered memory, maximum capacity up to 4TB. Provides 80 PCIe 5.0 lanes for high‑speed NVMe SSD, network card and accelerator expansion. Three 16GT/s UPI links enable stable dual‑socket 2‑processor operation. Built‑in Intel AMX matrix acceleration, AVX‑512 instruction set, improving AI inference and large‑data computing performanceIntel.
This CPU adopts FCLGA4677 socket. Widely deployed in enterprise database server, large‑scale virtualization host, cloud computing node and mid‑high end data center business. Dedicated high‑performance server cooling solution is required for stable full‑load operation.
1. 24‑Core 48‑Thread Balanced Mid‑High Tier Dual‑Socket Enterprise Server Processor
The Intel Xeon Gold 6442Y belongs to 4th‑generation Intel Xeon Scalable Sapphire‑Rapids family. Equipped with 24 physical cores and 48 SMT multi‑threads, this processor delivers well‑balanced single‑thread responsiveness and multi‑thread throughput. It supports single‑socket and dual‑socket FCLGA4677 platforms, perfectly suited for mainstream data‑center deployment, covering workloads of virtualization, relational database, HPC simulation and enterprise cloud hostsIntel。
2. 2.6GHz Base / Up to 4.0GHz Max Turbo Frequency & Large Shared Cache
Running at 2.6GHz base frequency and up to 4.0GHz maximum turbo frequency, it maintains stable continuous multi‑core performance while providing excellent burst single‑task performance. Built‑in 60MB shared L3 smart cache reduces memory access latency, accelerates database query, virtual machine scheduling and large‑scale batch‑data processing, improving overall server throughput under heavy long‑time enterprise loads. It supports Intel SST‑PP speed‑select performance profile for flexible power‑frequency tuning, configurable TDP down to 205WIntel。
3. 8‑Channel DDR5 Memory & Comprehensive PCIe 5.0 Expansion
Support 8‑channel DDR5‑4800 ECC registered memory (1DPC), maximum memory capacity up to 4TB per socket, supplies high‑bandwidth memory resources for memory‑intensive enterprise services. Offering 80 PCIe 5.0 lanes, compatible with high‑speed NVMe SSD, 100G network adapters and hardware accelerators. Adopt FCLGA4677 socket, match C700 series chipset motherboards, equipped with 3 UPI links running at 16GT/s for stable dual‑socket interconnection, supporting 24‑7 non‑stop data‑center‑grade operationIntel。
4. 225W Nominal TDP, SST‑PP Configurable Power & Full Enterprise‑Grade Technologies
Nominal 225W TDP, configurable TDP range 205‑225W via Intel SST‑PP profile, requires qualified high‑performance server cooling solution for full‑load stable operation. Integrated complete enterprise‑level functions: Intel VT‑x / VT‑d hardware virtualization, Intel AMX AI acceleration, AVX‑512 advanced instruction set, ECC error correction and platform security enhancement. It supports large‑scale virtual machine deployment, container operation and AI inference workloads. Note: This processor has no integrated graphics output。
5. Datacenter‑Grade IC Reliability & Broad Enterprise Compatibility
Manufactured under strict Intel server‑grade specifications, Tcase maximum operating temperature 79°C, DTS max temperature 95°C, designed for long‑term round‑the‑clock operation. Widely applied for new server assembly, data‑center capacity expansion, hardware refresh and premium refurbished server reconstruction. It is a balanced mainstream Sapphire‑Rapids compute component for modern enterprise infrastructureIntel。
表格
Item | Specifications |
|---|---|
Part Number | Intel Xeon Gold 6442Y |
Product Series | 4th Gen Intel Xeon Scalable (Sapphire Rapids) Server Microprocessor IC |
Architecture | Sapphire Rapids |
Process | Intel 7 |
Core / Thread | 24 Cores / 48 Threads (SMT Enabled) |
Base Frequency | 2.6 GHz |
Max Turbo Frequency | Up to 4.0 GHz |
L3 Cache | 60 MB Smart Cache |
Default TDP | 225 W |
Configurable SST‑PP TDP | 205‑225 W |
Socket | FCLGA4677 (Support 1P / 2P), 3 UPI links @16GT/s |
Memory Support | 8‑Channel DDR5‑4800 ECC (1DPC), Max 4TB per socket |
PCIe Version | PCIe 5.0, 80 Lanes |
Integrated Graphics | None |
Key Instruction | AMX, AVX‑512, SSE4.2, AES‑NI, TSX‑NI, Intel DL Boost |
Virtualization | Intel VT‑x, VT‑d |
Max Case Temperature | 79°C |
DTS Max Temperature | 95°C |
Core Advantages | Balanced 24C48T multi‑thread & single‑core frequency performance, Intel AMX AI acceleration, flexible SST‑PP power adjustment, 8‑channel DDR5‑4800, PCIe5.0, dual‑socket capability, good cost‑efficiency for mid‑high‑end data‑center scenarios |
Application Grade | Data‑Center Servers, Virtualization Hosts, Enterprise Database Nodes, HPC & Batch Computing, Enterprise Hardware Refresh & Refurbishment |
1. Enterprise Virtualization & Cloud Computing Server Nodes
Xeon Gold 6442Y serves as balanced compute core for mid‑high‑end virtualization servers. 24‑core 48‑thread resources support moderate‑large quantities of concurrent virtual machines and container instances, improving hardware utilization for private cloud and enterprise IT infrastructure.
2. Enterprise Database & Storage Servers
8‑channel high‑speed ECC memory and large cache deliver stable low‑latency performance for relational database, distributed storage and backup workloads. ECC error‑correction guarantees data integrity for core business data services.
3. HPC Simulation & Offline Batch Computing Nodes
Balanced multi‑thread capability plus AMX acceleration handle scientific simulation, numerical calculation, media transcoding and AI inference batch‑task scheduling, suitable for medium‑size compute cluster deployment.
4. Dual‑Socket Rack‑Mount Server Deployment
Support dual‑socket configuration via three UPI links. Widely adopted for new‑machine building and data‑center capacity expansion, balancing compute capability and procurement cost.
5. Server Refurbishment & Bulk Enterprise Hardware Replacement
Mature 4th‑gen Xeon Scalable CPU with stable FCLGA4677 platform compatibility. Frequently used for refurbished server reconstruction and enterprise legacy‑equipment upgrade projects.
