Xeon 4210
Xeon Silver 4210 belongs to Intel 2nd‑Generation Xeon Scalable Cascade Lake series, built on 14nm manufacturing process, equipped with 10 cores and 20 threads via Intel Hyper‑Threading technology. Base frequency 2.2GHz, maximum turbo frequency up to 3.2GHz, 13.75MB shared L3 cache, TDP 85W for balanced power and performanceIntel.
It supports 6‑channel DDR4‑2400 ECC registered memory, maximum memory capacity up to 1TB, does not support Intel Optane DC persistent memory. Provides 48 PCIe 3.0 lanes for high‑speed SSD and network card expansion. Two UPI links enable dual‑socket 2‑processor setup for multi‑CPU server platforms. Integrated AVX‑512 instruction set and Intel DL Boost for light computing accelerationIntel.
This CPU adopts FCLGA3647 socket. Widely used in mid‑range enterprise server, virtualization host, small business database, file storage server and backend service deployment. Dedicated server cooling solution is required for stable full‑load running.
1. 10‑Core 20‑Thread Mid‑Entry Enterprise Server Processor
The Intel Xeon Silver 4210 belongs to 2nd‑generation Intel Xeon Scalable Cascade Lake family, supports single‑socket and dual‑socket FCLGA3647 platforms. Equipped with 10 physical cores and 20 SMT multi‑threads, this processor delivers balanced multi‑thread computing capacity. It fits mid‑entry rack‑mount server deployment, meets demands of virtualization, storage service, small database and medium‑size business application workloads with outstanding cost‑performance.
2. 2.2GHz Base / Up to 3.2GHz Max Turbo Frequency & Practical Cache
Running at 2.2GHz base frequency and up to 3.2GHz maximum turbo frequency, it balances continuous multi‑core load performance and single‑task burst response. Built‑in 13.75MB shared L3 smart cache reduces memory access latency, accelerates virtual machine scheduling, business data query and batch task processing, maintaining stable throughput under long‑time enterprise operation.
3. Memory & Expansion Capability For Mid‑Entry Datacenter Workloads
Support 6‑channel DDR4‑2400 ECC memory, maximum memory capacity up to 1TB, compatible with Intel Optane persistent memory. Provide 48 PCIe 3.0 lanes, support high‑speed NVMe SSD, 10G network card and accelerator expansion. Adopt FCLGA3647 socket, match C620 series chipset motherboards, equipped with two UPI links for dual‑socket interconnection, stable for 24/7 non‑stop enterprise operation.
4. 85W TDP, Full Suite Of Server‑Grade Enterprise Technologies
With 85W nominal TDP, it brings moderate heat output and lowers server cooling requirements. Integrated enterprise‑level features: Intel VT‑x / VT‑d hardware virtualization, AVX‑512 advanced instruction set, AES‑NI encryption, ECC error correction. Supports virtual machine deployment, container running and enterprise data security requirements. Note: This processor has no integrated graphics output.
5. Datacenter‑Grade Reliability & Broad Refurbishment‑Market Compatibility
Designed under Intel strict server processor specifications, Tcase maximum operating temperature 87°C, supports round‑the‑clock continuous operation. Widely applied for new server assembly, small‑medium data center construction, second‑hand server reconstruction and enterprise hardware replacement. It is a mainstream cost‑effective Cascade Lake processor for aftermarket.
Item | Specifications |
|---|---|
Part Number | Intel Xeon Silver 4210 |
Product Series | 2nd Gen Intel Xeon Scalable (Cascade Lake) Server Microprocessor IC |
Architecture | Cascade Lake |
Process | Intel 14nm |
Core / Thread | 10 Cores / 20 Threads (SMT Enabled) |
Base Frequency | 2.2 GHz |
Max Turbo Frequency | Up to 3.2 GHz |
L3 Cache | 13.75 MB Smart Cache |
Default TDP | 85 W |
Socket | FCLGA3647 (Support 1P / 2P) |
Memory Support | 6‑Channel DDR4‑2400 ECC, Max 1TB, Intel Optane PMem supported |
PCIe Version | PCIe 3.0, 48 Lanes |
UPI Links | 2 |
Integrated Graphics | None |
Key Instruction | AVX‑512, SSE4.2, AES‑NI, TSX‑NI |
Virtualization | Intel VT‑x, VT‑d |
Max Case Temperature | 87°C |
Core Advantages | 10C20T balanced multi‑thread performance, low 85W power consumption, dual‑socket UPI support, Optane memory compatible, good cost‑efficiency for mid‑entry server and refurbishment projects |
Application Grade | Small‑Medium Datacenter Servers, Virtualization Hosts, Storage Servers, Small Database Nodes, Enterprise Hardware Refresh & Refurbishment |
1. Small‑Medium Enterprise Virtualization Host Servers
Xeon Silver 4210 works as core compute unit for entry‑to‑mid virtualization servers. 10‑core 20‑thread resources support moderate quantity of concurrent virtual machines and containers, improving hardware utilization for branch office and private cloud infrastructure.
2. Storage & Backup Database Servers
6‑channel ECC memory and decent cache deliver stable performance for NAS, distributed storage and lightweight relational database workloads. ECC function ensures data integrity for long‑term storage services.
3. Medium‑Size Business Application Servers
Capable of handling enterprise business services, web cluster, domain control and office application workloads, suitable for SME IT infrastructure deployment.
4. Dual‑Socket Rack‑Mount Server Deployment
Support dual‑socket configuration via UPI links, widely used for building low‑cost dual‑socket rack servers for scenarios requiring moderate compute scalability.
5. Second‑hand Server Refurbishment & Bulk Hardware Replacement
Mature Cascade Lake generation CPU with sufficient stock and excellent motherboard compatibility. Frequently used for refurbished server reconstruction and enterprise legacy‑equipment replacement projects.
